Board Configuration

Decoding Resolution

Supports almost all formats of H.264 1080p@60fps decoding, H.265 1080p@60fps decoding, H.264 1080p@30fps encoding, and high-quality JPEG encoding/decoding.

Main Functions

Operating System

Android 7.1.2

APP Functions

Customizable according to customer requirements.

Multimedia Support

Media Formats

Supports mainstream video formats including MPEG1, MPEG2, MPEG4, H.264, H.265, WMV, MKV, TS, flv; supports audio formats such as MP3; supports image formats including JPG, JPEG, BMP, PNG, GIF.

Basic Interfaces

Power interface

× 1

Ethernet interface

× 1，10/100M/1000M Ethernet

WiFi interface

× 1，WIFI(802.11a/b/g/n),compatible with 2.4G and 5G

USB OTG interface

× 1

USB2.0 interface

USB HOST × 7

I2C

× 2

Extended Function

RS232 × 2 / UART × 2, DEBUG × 1

MIPI

× 1

DP/EDP

× 2

Relay

× 1

HDMI

× 1

Speaker

× 2

TF Card

× 1

4G Module

× 1, 4G/7-band, external SIM card slot

Additional Functions

RTC (Real-Time Clock)

Real-time clock circuit

Watchdog Reset

Built-in watchdog, automatic recovery from abnormal status

Electrical Specifications

Input Power

12V 3A optional DC power input (power for amplifier, speaker, display and backlight are calculated separately)
