Board Dimension

160mm×214mm

CPU

Quad core ARM Cortex-A73   和 dual core ARM Cortex-A53

GPU

MaliG52 MP4

NPU

5TOPS

Memory

DDR Standard 4 GB (2 GB / 4 GB optional)

Built-in Storage

EMMC Standard 16G (16G,32G,64G,128G optional)

Operating System

Android9.0

Playback Modes

Support loop, scheduled, insertion and other playback modes

Network

100M Ethernet、

Support wireless peripheral extension、

2.4GHz WIFI (5G 、BT optional)

USB2.0 interface

4 external USB connectors

1single‑layer USB2.0 terminal

USB3.0 interface

1 single‑layer USB3.0 terminal

Serial Ports

4 UART connectors

HDMI Output

2 channels:

• 1 × HDMI OUT connector
• 1 × HDMI OUT terminal

Audio

1 x lineout

Timing Power On/Off

Supported

System Upgrade

Support OTG upgrade and USB flash drive upgrade

TF Card

Support insertion of TF cards，Increase storage capacity

SIM Card

SIM card*1
